MAGIC mixes Lua and BASIC, and it compiles to JavaScript. A script can load a canvas, a terminal, 3D, a UI kit, sound, hex grids, and a few game helpers. magic run runs it. magic app writes an Electron project. magic pack writes that same project, and magic pack --build also builds the standalone app.
@canvas loads a module. import does the same job when you want to name what you take.
@canvas
@games
let engine = new Engine({ width: 480, height: 270 })
let spark = engine.sprite("✦", 240, 135, 42)
fn frame()
if engine.isKeyDown("ArrowRight") then
spark.x = spark.x + 4
end
engine.update()
engine.canvas.draw()
requestAnimationFrame(frame)
end
requestAnimationFrame(frame)
This file is the door. LEARN.md is the short course. LANGUAGE.md is the language. MODULES.md is each module. lang/ is the machine-readable definition.
npm install
npm run demo
npm install compiles src/ into dist/ and writes the script-tag builds to browser/. npm run build does that again after you change the TypeScript. The demo runs a language check, a headless scene, the sound, hex, and games modules, a small desk, and an Electron folder. It prints demo ok.
npm run serve
Open the URL it prints, http://127.0.0.1:8740/ unless the port is taken. The site is the course, the module list, a playground, and the examples. magic serve --port 8740 is the same command.
npm run magic -- run examples/scene.magic
npm run magic -- compile examples/check.magic -o game.js
npm run magic -- app examples/scene.magic -o build/drift --title "Drift"
npm run magic -- pack examples/scene.magic -o build/drift --title "Drift"
node dist/cli.js is the same program. A project that depends on this package gets a magic command.
magic compile writes one JavaScript module. Magic files that the script imports are copied into that module. A standard module stays a package import: magic/canvas, magic/terminal, emoji-engine-3d, emoji-engine-ui, magic/sound, magic/hex, or magic/games. magic run --strict and magic compile --strict check the file the way @strict does.
magic app and magic pack write a folder. The window is 960 by 720 unless --width and --height say otherwise. The folder’s package.json depends on Electron and electron-builder. MAGIC does not install them unless you pass --build to magic pack.
cd build/drift
npm install
npm start
npm run pack
npm start opens the window. npm run pack writes a standalone app under dist/, a folder you can run without npm start. npm run dist writes installers. The window keeps contextIsolation on, nodeIntegration off, and sandbox on. tools/electron.md is the longer note.
msx runs a .magic file the way tsx runs TypeScript. js2magic turns JavaScript or TypeScript into a Magic draft. Both live in tools/.
@name at the top of a file loads a module and binds its exports. @name as local binds the module under one name.
| Module | Loads |
|---|---|
@canvas |
Canvas, Engine, Utilities |
@terminal |
Terminal, Utilities |
@2d |
Both halves of the 2D engine |
@3d |
The 3D engine |
@ui |
Windows, buttons, menus |
@sound |
Tones and notes |
@hex |
Hex grids |
@games |
Loops, keys, scenes, scores |
Canvas and terminal are the two halves of what used to be one 2d import. @2d still loads both when a script wants the whole set. @canvas and @terminal both export Utilities, so use @terminal as term when you load both.
import Engine from "canvas" is the same module, with the names you pick. The details are in MODULES.md.
LANGUAGE.md is every form and every rule. This is the shape.
Keywords ignore case. Names keep their case. A newline ends a statement. end closes if, while, for, repeat, fn, class, and try. then and do are optional. -- comments out the rest of the line. nil, false, 0, and "" are false. = assigns. == compares. Indexes start at 0. for i = 1 to 3 visits 1, 2, and 3.
fn greet(name)
return "Hello, " .. name
end
class Counter
n = 0
fn new(start)
self.n = start
end
fn bump()
self.n = self.n + 1
return self.n
end
end
print greet("Ada")
print Counter(1).bump()
@strict asks for the types you wrote, and for public, private, and protected on a class. A script that writes neither is unchanged. Types use as, so : can still end a statement.
| File | What it shows |
|---|---|
examples/hello.magic |
A function and print |
examples/check.magic |
The language check |
examples/scene.magic |
@canvas, a sprite, a collision |
examples/modules.magic |
@hex, @games, @sound |
examples/desk.magic |
A terminal and the UI kit |
examples/strict.magic |
Types and private fields |
examples/play.html |
Drift, in the browser |
import { compile, Runtime, App } from 'magic';
const runtime = new Runtime();
await runtime.runFile('examples/scene.magic');
const packed = App.pack('examples/scene.magic', {
out: 'build/drift',
title: 'Drift',
});
const script = compile(source, { filename: 'play.magic', target: 'script' });
new Function(script.code)();
A page loads browser/magic.js and calls Magic.compile. That build is the compiler. browser/magic-stdlib.js is sound, hex, and games. The picture modules come from the engine browser builds.
